Product Details
✓AT9310 can provide 5kVAC/10mA withstand voltage, 6kVDC/10mA withstand voltage, and insulation resistance testing.
✓AT9320 can provide 5kVAC/20mA withstand voltage, 6kVDC/10mA withstand voltage, and insulation resistance testing.
✓Three in one AC withstand voltage, DC withstand voltage, and insulation resistance testing;2U standard chassis;Floating test
✓Enhance anti-interference capability;It can independently conduct AC withstand voltage testing, DC withstand voltage testing, and insulation resistance testing, and can also perform multi item sequential testing through the project settings of the testing plan.
✓Output Voltage:0.050kV-1.000kV DC,Resolution: 1V, Voltage Accuracy:1% of reading + 2 digits; Measurement Range:0.1MΩ-10GΩ; Testing Time:0.2s-999.9s;Power Supply:198V ~ 242V 50/60Hz,400VA
